Dynojet Power Vision

Dynojet Power Vision

Save 10% Save 9%
$1,196.95
$59.95 - $1,196.95
$1,196.95
$1,089.95
$59.95 - $1,089.95
$1,089.95

POWER VISION 3

Dynojet's Latest Power Vision is the 3rd incarnation of the world's most powerful flash tuning system. Designed to cover more models than ever before, you can now unlock the secrets that are hiding in your ECM.

Nobody offers more! The Power Vision from Dynojet has more pre-configured tunes, extensive calibration access for custom tuning, industry exclusive features, and world class support. For ease of use, all supported models can be flashed via the diagnostic port and many are able to be read in the same manner.

Flash ECU via vehicle diagnostic connector (no need to open or remove ECU from the vehicle)

Read original tune via diagnostic connector, or virtual read with server download

Display and / or log vehicle data channels in real-time

"Hindsight" feature captures last 2 minutes of data with the touch of a button

Weather resistant for use in all conditions

Vivid colour display with high contrast ratio (view-able in direct sunlight)

PERFORMANCE TUNE FEATURES

Support for popular aftermarket performance parts

Fuelling revised for maximum power and torque

Spark timing optimised for pump or race fuel

Rev and speed limits raised

Torque limiting functions reduced or eliminated

Revised drive by wire throttle profiles

....And much more

POWER CORE SOFTWARE

SUITE C3 TUNING SOFTWARE

Tune editor offers full support with expansive calibration definition to allow comprehensive and precise control

Powerful compare feature to identify difference and similarities

Value file feature allows you to save specific calibration changes

Live cell tracing or synchronised offline cell tracing during data log review

Helpful tuning parameter descriptions

Extremely flexible to tailor the environment to the users preference

Tune lab allows users to use pre-developed scripts to correct tuning variables like volumetric efficiency tables

WINPEP 8 DATA CENTRE

Runs simultaneously and synchronises with C3 to show cell tracer in tuning tables

WINPEP 8 DYNO CENTRE

For Dynojet dyno owners with dynoware RT electronics, stream real-time data from supported vehicles during dyno runs sessions

Control dyno run sessions to maximise efficiency, especially when using conjunction with tune lab

EXPLORE THE POSSIBLITIES

No matter your brand of motorcycle or style of riding, our fuel tuners can help optimize it for power, speed or fuel-efficiency. With our extensive library of dyno-tested tunes and the ability to flash your ECU from the road, you’ll have a tune for any trip. Our Power Vision easily connects to your motorcycle through the OEM-style connectors, so installation is a snap. You can then flash your bike and unplug the device, or you can use it as an instrument panel for more information on your fuel efficiency, air/fuel ratio, and more. It was also built to last with a weather and shock-resistant exterior. Our Power Vision for Harley-Davidson even has a unique autotune capability that can monitor the way you ride and create a custom tune suited just for your riding style.

  • Flash performance tunes via OEM diagnostic connector, no need to remove and send out ECU
  • Display vehicle data channels in real-time
  • Weather-resistant for use in all conditions
  • High contrast display, viewable in direct sunlight

MADE FOR UPGRADES

Our Power Vision can hold multiple tunes right on the device, which means that you can reflash your ECU changing conditions right from the road. Keep a tune available for each of your favorite upgrades and drive styles to optimize your vehicle for everything you need.

STAY CONNECTED

Not just a fuel tuner, the Power Vision is also a powerful monitoring tool to track your progress as you ride. The data can then be seen using our Power Core Software to help you improve your tune. It also has the compatibility to be used as an extra instrument panel when mounted to the bike for even more control over your progress.

UNLOCK YOUR POTENTIAL

  • PC-based
  • Connects dynamometer runs with fuel tuners
  • Adjusts/creates calibrations and maps

POWER VISION

Power Vision is the most powerful and quickest flash tuning device for Harley-Davidson® motorcycles in the market today. It is a performance tuner and data monitor that offers the latest flash tuning technology, data logging, and other industry exclusive features. The Power Vision can tune any fuel injected Harley-Davidson motorcycle with the Delphi ECM , including 2018 models. The Power Vision Product Suite includes a full color touch screen flash device, built in Auto Tune Basic Mode*, vehicle interface cable, and WinPV (Windows PC based tuning application).

The Power Vision incorporates a very sophisticated, yet simple touch screen display that DOES NOT require the use of a computer to flash your bike or to use Auto Tune!* Simply select the tune, follow the on-screen prompts to download the tune, and if you’d like, edit your tune without ever touching a computer! That’s right, you can flash and make changes to your tune without ever getting off your bike.

CAPABILITIES

Power Vision downloads and stores the stock calibration, and lets you select up to 8 different tunes that are stored on the device, and can be flashed to your bike. The types of tunes include:

  • Dynojet Preconfigured Tunes - Tunes for YOUR bike pre-loaded on the device... ready to go, right out of the box! Power Vision identifies your bike’s information and automatically sorts hundreds of applicable dyno proven tunes for you to choose from.
  • Custom Tunes – loaded by a custom tuning shop, or received via email and loaded on the device.
  • Copy of Original or Copy of Current - a version of the Original calibration that was saved when the Power Vision was married to the ECM. Or a version of the Current calibration that is currently saved in the ECM.

Power Vision provides insightful, valuable information on how your bike is running:

  • Display all J1850 and CAN H-D vehicle data as well as wide band air/fuel ratio1and various channels (such as MPG instant and trip MPG)
  • AutoTune2 Basic and Pro– AutoTune is built into the Power Vision so you can modify your tune as you ride without using a computer
  • Check and clear diagnostic codes
  • Reset adaptive fuel trims and idle offset (with bike running)

1When fitted with AutoTune Pro

2AutoTune Basic is included in the Power Vision for use with bikes equipped with stock narrow-band O2 sensors. AutoTune Pro utilizes wideband O2 sensors and requires the AutoTune Pro accessory

SEVERAL WAYS TO OBTAIN POWER VISION TUNES (MAPS)

There are three types of tunes that you can deliver to your bike: pre-configured tunes (loaded on the device from Dynojet), custom tunes (loaded or emailed to you by a custom tuner, or you can use a copy of your original tune to tweak. If you choose to use the pre-configured tunes, the device will identify the ECM strategy / software level of the stock calibration, and then automatically sort applicable tune files in groups of relevant modifications for YOUR bike.

Hundreds of tunes are available and the organized into relevant categories (ie, stock improved, air intake kits, slip-ons, full exhaust systems, cams, etc.) for ease of customer use. The Power Vision holds up to 8 tunes (any combination of the 3 types) for you to choose from at your convenience, and these can be replaced as many times as you like with updated tunes.

POWER VISION DEVICE FEATURES / SPECIFICATIONS

FEATURES

  • Flash tune any 2001-Present Softail, 2002-Present Touring, 2002-Present V-rod, 2004-Present Dyna and 2007-Present Sportsters!
  • Sophisticated, yet simple touch screen display that DOES NOT require the use of a computer to flash your bike. Simply select the tune and follow the on-screen prompts to download the tune.
  • Integrated AMPS 4 hole threaded inserts for various mounting solutions
  • Power Vision downloads and stores the stock calibration in the event you need to restore the OEM calibration
  • Flexibility – choose from Dynojet Pre-Configured tunes, Custom Tunes, or use a copy of your stock tune to fit the needs of your bike.
  • On-Device Tune Editing – allows users to change / edit basic tuning parameters on the device, and then deliver the changes to the vehicle ECM without using a computer.
  • Display all J1850 and CAN H-D vehicle data as well as wide band air-fuel ratio1 and various calculated channels (such as MPG instant and trip MPG)
  • Customizable virtual gauges allow data to be monitored live, and / or logged while riding
  • User defined visual alarms for any data channel (example, if knock exceeds 2 degrees, or if Cylinder Head Temp exceeds 280 degF, enable visual alarm).
  • AutoTune2 Basic and Pro – calculates and stores fuel trims to optimize fuel curve
  • Check and clear diagnostic codes
  • Reset adaptive fuel trims and idle offset (with bike running)

POWER VISION DEVICE SPECIFICATIONS

  • 3.5 24bit color TFT (touch screen) display with touch panel (16,777,216 colors)
  • Compact Dimensions: 2.83L X 3.97W X .84H (click on link for visual)
  • Weather, shock, and vibration resistant enclosure - fully potted with silicone elastomer, and utilizes over molded cables with sealed cable connections
  • Integrated AMPS 4 hole threaded inserts for various mounting solutions (Dynojet recommends TechMounts)
  • USB mini-B weatherized- compatible with Windows XP, Vista, and 7
  • Molex 8 pin connector -to- vehicle interface cable
  • Dynojet CAN-Link Expansion Port allows interfacing with other Dynojet products, such as the Wide Band 2 or Auto Tune Module1
  • 2GB of internal memory provides a robust capacity for tune files and data logs

1When outfitted with a Dynojet Auto Tune or Wide Band 2 System
2When used in conjunction with Log Tuner software
